Fire Alarm Security Entrance Turnstile Gates Emegency Access Controlled Arm Swing Barrier

Shenzhen Jiaxuntong Computer Technology Co., Ltd.
Contact Now

Fire Alarm Security Entrance Turnstile Gates Emegency Access Controlled Arm Swing Barrier

Brand Name : Jiaxuntong

Model Number : Cf238FLG

Certification : CE

Place of Origin : Made in China

MOQ : 1 set

Payment Terms : T/T

Supply Ability : 500set/ month

Packaging Details : wooden package

Product name : Arm Swing Barrier

Box Materias : ss304

Arm wing : Plexiglass Galss steel

Driving Motor : Brcush DC motor

Net weight : 70-80KG

Compatibility : dry contact signal input interface

Contact Now

Fire Alarm Security Entrance Turnstile Gates Emegency Access Controlled Arm Swing Barrier


Swing Gates Parameter :

Material: SS304,thickness is no less than 1.5mm

Manufacturing Technique: CNC laser cutting

Barrier Material: Acrylic glass, SS304 and so on

Gate Opening and Closing time: ≤ 0.4S

Passing Speed: Normally open-50persons/min; Normally closed-50persons/min

Communication Connection: RS485 Communication

Power: AC220C±10V,50HZ

Motor: DC Brushless Motor, 140W/24V

Communication Distance: ≤1200M

10) Input Connection: +12V Level Signal or Pulse Wide>100ms DC12V pulse, Current>10Ma

11) Infrared Sensors: 9 or 10 Pairs

12) Relative Humidity: <95%, No Densation

13) Operating Temperature: -15°C-60°C

14) Working environment: indoor and outdoor(added the rain-shed)

15) Color: SSB(US32D)-Stainless Steel Brushed / Powder Coating(Optional), or other Color you like

Features

1-The turnstile housing is made of stainless steel, seamless design.

2-The internal structures are all under rustproof processing, so the turnstile will be durable.

3-The machine works smoothly without any noise.

4-The swing can be pushed freely when the power is off, and it can be the emergency passageway.

5-The system adopts standard electrical interfaces.

6-Compatible with all main access control card readers

7-Be suitable for the different security grade access control passageways

8-To effectively prevent the illegal person entering and exiting

Interface

Fire Alarm” control input to unlock the turnstile when an appropriate signal is received from fire alarm system or emergency button.
Relay outputs to connect remote light indicators,an intrusion detector,a siren and an emergency unlocking device.
Galvanic decoupling of the outputs to ensure noise-immunity of the turnstile electronic.
The logic is protected again short circuits,overloads and polarity inversion.

Fire Alarm Security Entrance Turnstile Gates Emegency Access Controlled Arm Swing Barrier
